Utility Press ( DP-420T )
PRODUCT FEATURES
-
Self-contained vacuum.
-
Automatic motor stop (after 10 seconds).
-
Inverter for Vacuum Motor.
PRODUCT SPECIFICATIONS
-
Power : Single Phase, 220V, 5A
-
Weight : 690 lbs.
-
Air Consumption : 12.5 liter / cycle
-
Steam Consumption : 0.6 hp / 10 Kg/h
-
Air Pressure : 73 psi / 0.5 Mpa
-
Steam Pressure : 85 psi / 0.6 Mpa
-
Air Connection : 3/8
-
Steam Connection : Inlet 1/2, Outlet 1/2
-
Dimension (Width x Depth x Height) : 1895x1005x1550 (mm) 62.8x3906x61 (inch)
