Product Features

• Self-Contained Vacuum – Efficient and reliable operation.
• Automatic Motor Stop – Shuts down automatically after 10 seconds to save energy.
• Vacuum Motor Inverter – Provides precise control and improves motor efficiency.

Product Specifications

• Power Supply: Single Phase, 220V, 5A
• Weight: 690 lbs
• Air Consumption: 12.5 liters / cycle
• Steam Consumption: 0.6 hp / 10 kg/h
• Air Pressure: 73 psi (0.5 MPa)
• Steam Pressure: 85 psi (0.6 MPa)
• Air Connection: 3/8 in.
• Steam Connection: Inlet 1/2 in., Outlet 1/2 in.
• Dimensions (W × D × H):
  • 1895 × 1005 × 1550 mm
  • 62.8 × 3906 × 61 in. (Note: The inch conversion seems off — 3906 inches ≈ 325 feet; likely a typo in original data.)
