Product Features

• Shoulder Press – Specially engineered to deliver the best possible press in hard-to-finish areas.
• Steam Injection – Advanced steam injection system covers the full body width. Combined with a heated buck body, it significantly reduces processing time.
• Tensioning Tuck Press – Equipped with a new lower tuck clamp and tensioning function, ensuring superior tuck finish quality.
• Side Expanders – Enhanced expanders open early to eliminate wrinkles and improve overall finish.

Product Specifications

• Power Supply: 3 Phase, 220V, 12A
• Weight: 2,700 lbs
• Air Consumption: 56 liters / cycle
• Steam Consumption: 105 kg / hour
• Air Pressure: 85 psi (0.6 MPa)
• Steam Pressure: 110 psi (recommended for optimal use)
• Air Connection: 3/8 in.
• Steam Connection: Inlet 3/4 in., Outlet 1/2 in. × 3
• Dimensions (W × D × H):
  • 2380 × 2270 × 2100 mm
  • 94 × 90 × 82.7 in.
