Product Features

• Steam Injection – Advanced system covers the entire body width; combined with a heated buck body, it reduces processing time.
• Tuck Press – New lower tuck clamp with tensioning function improves tuck finish quality.
• Side Expanders – Enhanced expanders open early to eliminate wrinkles.
• Wide Body Pressing Technology – Larger front and rear press heads increase production on larger shirts.

Product Specifications

• Power Supply: 3 Phase, 220V, 10A
• Weight: 1,600 lbs
• Air Consumption: 48 liters / cycle
• Steam Consumption: 3 hp / 50 kg/h
• Air Pressure: 85 psi (0.6 MPa)
• Steam Pressure: 110 psi (optimal use)
• Air Connection: 3/8 in.
• Steam Connection: Inlet 3/4 in., Outlet 1/2 in. × 3
• Dimensions (W × D × H): 97.5 × 47.5 × 79 in.
